Sawdust block making machine for sale

Sawdust block making machine is the equipment producing sawdust block used for pallet, which mainly includes three types of specifications: single-head, double-head, three-head pallet block making machine.

sawdust block making machine

Sawdust block making machine working principle

  1. The hydraulic cylinder provides high pressure and pushes the piston to extrude and mold the materials.
  2. The heating of the heating plate at a high temperature promote the solidification and molding of urea-formaldehyde glue, and thus to increase the strength of the block.
  3. The products extruding from the compressed sawdust pallet block machine is cut according to certain length (usually around 1.2 meters).
  4. After cooling, then the second cutting. The reason for cooing is that the end product just formed by the machine is very hot and relatively soft, the temperature is about 60 degrees centigrade. If cut the products at this time, the cut surface will be very rough.
  5. Then cut the long strips of half-finished products to the final size you need. The block is finished.
The sawdust block is used to make the wood pallet feet, which is for the transportation or storage pallet. The final product could get the E1 grade. The pallet feet could be solid without hole in the center, and also could be hollow.

Sawdust block making machine features

  • Free of fumigation. Because the block is made by hot pressing, it is free of fumigation.
  • It could recycle the wood waste efficiently.
  • Easy to operate. one person could handle 3 machines.
  • Density of final product could get to 550-1000 kg/m3.
  • One machine could make two different block sizes. And you could choose what you need.

Normally block size is 90*90 mm, 90*100 mm, 100*100 mm, 80*90 mm. If you have special requirements, we could customize machine for you. While, it ranges from 75 mm to 145 mm.

Sawdust block making machine parameter

Pallet block machine
Size (mm) 4800*780*1320 4800*780*1320 4800*900*1420
Length and width of block (mm) 75-145
Power (kW) 16.86 22.26 22.26
Density (kg/m3) 550-600
Production efficiency (m3/24 hours) 2-5 3-6 5-9
Dimension with saw (mm) 8000*600*1500 8000*700*1500 8000*700*1500
Weight (kg) 1000 1500 2000
Block size: 75-145 mm in width, 75-145 mm in length. Customized service is available.
